The OPC DA server enables access to process data e.g. instantaneous values or totalizers from the connected Endress+Hauser field devices. The OPC server provides the data to OPC clients in real time. With an OPC client software the process data can be visualized. Communication is made either by using an RS232/RS485 interface or a TCP/IP connection. OPC is applied in areas of factory and process automation independent of their size.
The OPC Server can communicate with the following devices:
Ecograph A, Ecograph T
Memograph, Memograph S, Memograph M
Alphalog
RMS621, RMC621, RMM621
FML621
RA33, EngyCal RH33, EngyCal RS33
Benefits
Easy connection to process visualization systems via standard interface OPC
Ask any experienced plant manager, operator or engineer about their career experiences, and they can recall multiple instances attempting to troubleshoot issues with insufficient information available
Unmeasured losses in tanks, vessels and terminal operations can cost millions of dollars if instrumentation isn't accurate. Download the white paper to learn more about potential cost savings!
The OPC DA Server allows data access to instantaneous values from different Endress+Hauser devices. These data are made available to OPC clients in real time. Communication is made either by using an RS232/RS485 interface or a TCP/IP connection. The OPC server supports the Ecograph the Memograph the Energy manager family the batch controller.
Operating systems
Microsoft Windows 2000 SP4 Microsoft XP SP2 (32 Bit) Microsoft Windows Server 2003 Windows 2008 Server (32/64 Bit) Microsoft Vista (32 Bit) Windows 7 (32/64 Bit) Windows 8 (32/64 Bit) Windows 10 (32/64 Bit)
Processor type
Pentium 200 MHz (≥400 MHz recommended)
Main memory
At least 128 MB
Hard-disk capacity
Disk space needed: At least 100 MB
Registered Trademarks
Microsoft Windows Windows XP Windows 8 and the Microsoft logo are registered trademarks of the Microsoft Corporation. All other brand and product names are trademarks or registered trademarks of the companies and organisations in question.
